Noise is only one of the reference factors and is by no means the only criterion for selecting the reducer series.
1. Why can’t we just look at the noise to select the level?
The number of reducer stages (single-stage, two-stage, three-stage, multi-stage) core determines the reduction ratio range, output torque, volume shape, transmission efficiency, load-bearing capacity, installation space, and cost. Noise is only an incidental feature.
2. Core key factors in selecting reducer series
1. Required total reduction ratio
The single-stage reduction ratio range is small, and only two or three stages can achieve a large speed ratio; if the speed ratio cannot be reached, it cannot be used no matter how quiet it is.
2. Output torque and load carrying capacity
The more stages, the more transmission levels, which can amplify greater torque. Heavy-load conditions must match the corresponding stages.
3. Transmission efficiency and energy consumption
The more stages there are, the greater the meshing loss and the lower the efficiency. For working conditions with high energy saving requirements, a smaller number of stages is preferred.
4. Installation space and Dimensions
Multi-stage reducers are larger in size and longer in length; only a small number of stages or special structures can be selected due to limited space.
5. The operating speed matches the input speed
High and low speeds, frequent starts and stops, and forward and reverse rotation conditions require far greater series and structural matching than noise.
6. Cost and service life
The higher the level, the more complex the structure, and the higher the cost of construction and maintenance; for light loads, there is no need to choose multiple levels to increase costs.
7. Accuracy and backlash requirements
In servo and precision control scenarios, the series directly affects the return gap and positioning accuracy, and the priority is higher than noise.
3. The simple relationship between noise and series
Generally, for the same type of reducer, the more stages and meshing points, the theoretical noise will be slightly lower. However, noise can be reduced through processing accuracy, gear grade, lubrication, and shell structure. It is not necessary to simply increase the number of stages to reduce noise.
Summary: When selecting the reducer series, first look at the speed ratio, torque, space, efficiency, and working conditions, and then consider the noise. Noise can only be used as an auxiliary filtering condition.
